CDM-625A Advanced Satellite Modem
Appendix L
ACM converts available link margin into additional throughput, thereby maximizing throughput
under all conditions, including rain fade, inclined orbit satellite operation, antenna mispointing,
interference and other impairments.
L.2.4 Subsystem Multiplex (Sub-Mux)
Appendix N. IP SUB-MUX
Sub-Mux is a secondary framing structure that combines IP traffic with any currently available
combination of framing and interface type (excluding IP itself). A specific, user-selected ratio
references the composite data rate to the modulator and from the demodulator to the primary,
non-IP interface rate.
Sub-Mux capability can be used with the IP Packet Processor to multiplex a primary serial
synchronous or G.703 traffic stream with IP.
L.2.5 FAST Options
• Chapter 5. FAST ACTIVATION PROCEDURE
• Sect. 6.2.8 SELECT: FAST Menus (Chapter 6. FRONT PANEL OPERATION)
If there is a need to upgrade the CDM-625A IP Packet Processor's functionality, Comtech EF Data
provides Fully Accessible System Topology (FAST), a technology that permits the purchase and
installation of options through special authorization codes. These unique Fast Access Codes may
be purchased from Comtech EF Data during normal business hours, and then loaded into the
unit using the front panel keypad.
Contact Comtech EF Data Product Support to acquire the following available FAST options:
•
Quality of Service (QoS)
•
AES Encryption
• Header Compression:
o Up to 5 Mbps (CCM) / 1200 ksps (ACM)
o Up to 15 Mbps (CCM) / 4100 ksps (ACM)
o Up to 25 Mbps (CCM) / 4100 ksps (ACM)
•
Payload Compression:
o Up to 5 Mbps (CCM) / 1200 ksps (ACM)
o Up to 15 Mbps (CCM) / 4100 ksps (ACM)
o Up to 25 Mbps (CCM) / 4100 ksps (ACM)
o Up to 10 Mbps (CCM) / 4100 ksps (ACM)
o Up to 20 Mbps (CCM) / 4100 ksps (ACM)
o Up to 10 Mbps (CCM) / 4100 ksps (ACM)
o Up to 20 Mbps (CCM) / 4100 ksps (ACM)
