CDM-625A Advanced Satellite Modem
Serial-based Remote Product Management
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Equipment ID
(cont.)
Description of Arguments
X=Advanced QoS, where:
0=Not installed
1=Installed
Y=AES Encryption, where:
0=Not installed
1=Installed
Z= Advanced NetworkTiming, where:
0=Not installed
1=Installed
a= Carrier ID, where:
0=Not installed
1=Installed
b=CnC Activation, where:
0=Not installed
1=Installed
sss = spares (0)
600/L Emulation: See CDM-600/600L manual
Example: EID=A62510000010134484312105511111000 indicates all software options, TPC/LDPC card installed.
Note: To achieve LDPC or TPC to 25 Mbps, the modem will require:
• Hardware option B, slot 1, a TPC/LDPC Codec;
• Software options: L: data rate FAST option to 25 Mbps AND M:TPC/LDPC data rate FAST option to 25 Mbps.
8–49
Revision 0
MN-CDM625A
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
