CDM-625A Advanced Satellite Modem
Introduction
EDMAC, EDMAC-2, or EDMAC-3 (NO REED SOLOMON)
No FEC, BPSK
No FEC, O/QPSK
VITERBI, BPSK, 1/2
VITERBI, O/QPSK, 1/2
VITERBI, O/QPSK, 3/4
VITERBI, O/QPSK, 7/8
SEQUENTIAL, BPSK, 1/2
SEQUENTIAL, O/QPSK, 1/2
SEQUENTIAL, O/QPSK, 3/4
SEQUENTIAL, O/QPSK, 7/8
TRELLIS, 8PSK, 2/3
TPC, BPSK, 5/16
TPC, BPSK, 21/44 (aka 1/2)
TPC, O/QPSK, 21/44 (aka 1/2)
TPC, O/QPSK, 3/4
TPC, O/QPSK, 17/18 (aka 0.95)
TPC, O/QPSK, 7/8
TPC, 8PSK/8-QAM, 3/4
TPC, 8PSK/8-QAM, 17/18 (aka 0.95)
TPC, 8PSK/8-QAM, 7/8
TPC, 16-QAM, 3/4
TPC, 16-QAM, 7/8
LDPC, BPSK, 1/2
LDPC, O/QPSK, 1/2
LDPC, O/QPSK, 3/4
LDPC, O/QPSK, 2/3
LDPC, 8PSK/8-QAM, 3/4
LDPC, 8PSK/8-QAM, 2/3
LDPC, 16-QAM, 3/4
EDMAC, EDMAC-2, or EDMAC-3 (ANY REED SOLOMON)
VITERBI, BPSK, 1/2
VITERBI, O/QPSK, 1/2
VITERBI, O/QPSK, 3/4
VITERBI, O/QPSK, 7/8
SEQUENTIAL, BPSK, 1/2
SEQUENTIAL, O/QPSK, 1/2
SEQUENTIAL, O/QPSK, 3/4
SEQUENTIAL, O/QPSK, 7/8
TRELLIS, 8PSK, 2/3
VIT 16-QAM, 3/4
VIT 16-QAM, 7/8
Lower Limit (kbps)
18.0
35.5
18.0
18.0
26.6
31.0
18.0
18.0
26.6
31.0
35.5
18.0
18.0
18.0
26.6
33.5
31.0
39.9
50.2
46.5
53.2
62.0
18.0
18.0
26.6
23.7
39.9
35.5
53.2
Lower Limit (kbps)
18.0
18.0
24.0
27.9
18.0
18.0
24.0
27.9
31.9
47.9
55.8
1–25
Revision 0
MN-CDM625A
Upper Limit (kbps)
12295.0
24590.1
6147.5
12295.0
18442.6
21516.3
1024.0
2048.0
2048.0
2048.0
24590.1
3842.2
5868.1
11736.2
18442.6
23224.0
21516.3
24590.1
24590.1
24590.1
24590.1
24590.1
6147.5
12295.0
18442.6
16393.4
24590.1
24590.1
24590.1
Upper Limit (kbps)
5532.7
11065.5
16598.3
19364.7
1024.0
2048.0
2048.0
2048.0
22131.1
22131.1
22131.1
