CDM-625A Advanced Satellite Modem
Serial-based Remote Product Management
Command
Parameter
Number of
(Instruction
Type
Arguments
& Qualifier)
...Global
Configuration
(cont.)
OGC Outdoor Unit
OGC=
50 Bytes
Global Copy
Description of Arguments
BBBCCC=CnC search delays
D=CnC PMSI mode
ee=Compressed Ethernet port speed
E=Attach summary BUC alarm to Tx
F=Attach summary LNB alarm to Rx
GGG=WAN buffer length
H=Dedicated Management Port
Note: Much of the CDM-625A MGC format has been kept similar to the 600/L MGC format.
* indicates differences.
** Ethernet port speed is compressed from 4 bytes in SEC command to 2 bytes in MGC. First byte represents speed
settings for Port 1 and Port 2, second byte represents speed settings for Port 3 and Port 4. In each byte, character A
through Y is used to represent 25 possible combinations of two port speed.
A=00, B=01, C=02, D=03, E=04, F=10, G=11, H=12, I=13, J=14, K=20, L=21, M=22, N=23, O=24, P=30, Q=31, R=32,
S=33, T=34, U=40, V=41, W=42, X=43, Y=44.
Example: BN is converted to 0123, that means Port 1 is AutoNeg, Port 2 is 100Full, Port 3 is 100Half, Port 4 is 10Full.
Command or Query.
ODU Global Configuration of CDM-625A, in the form shown in the Response to Query column (to the right), where:
aa=BUC Address
b=BUC Tx Output Enable
* x (spare)
d=BUC Power Supply
e=BUC 10MHz Reference State
xxxxx (spares)
gggg=BUC Current - Low Limit
hhhh=BUC Current - High Limit
* xxxx (spares)
* i=LNB Power Supply
* x (spare)
k=LNB 10MHz Reference
lll=LNB Low Alarm Limit
nnn=LNB High Alarm Limit
FFFFFS=TX LO Frequency
fffffs=RX LO Frequency
xxxxxx (spares)
Notes:
1.
Much of the CDM-625A OGC f ormat h as be en kept s imilar t o t he C DM-600L O GC f ormat ( * i ndicates t he
differences). In 600L Emulation Mode, OGC follows the CDM-600L's OGC format.
2.
Any unavailable parameters will be filled with x's.
same as CSD
same as CPM
see **
same as ABA
same as ALA
same as WBL
same as DMP
same as BAD
same as BOE
same as BPS
same as BFR
same as BCL
same as BCH
same as LPS
same as LNR
same as LNL
same as LNH
same as TLO
same as RLO
8–42
Revision 0
MN-CDM625A
Query
Response to
(Instruction &
Response to Query
Command
Qualifier)
OGC=
OGC?
OGC=aabxdexxxxxggg
OGC?
OGC?n (where n =
ghhhhxxxxixklllnnnFFF
OGC*
0 to 9. Returns the
FFSfffffsxxxxxx
OGC#
OGC portion of 1 of
10 stored
(Returns current OGC
configurations)
Configuration)
