Comtech EF Data CDM-625A Installation And Operation Manual page 640

CDM-625A Advanced Satellite Modem
Appendix L
Step Task
6 Prepare t he I P P acket P rocessor C ard f or i nstallation b y
aligning i ts r eceptacle w ith t he m ating c onnector o n t he
modem's framing board.
Plug t he c ard f irmly i nto t he connector – take c are no t t o
damage a ny t op-mounted c omponents. S imilarly, b e sure
not to d amage t he b ottom of t he card o n t he chassis'
mounting bosses while plugging the card receptacle into its
mating connector.
Installation i s c omplete o nce t he c able c onnector i s f ully
engaged w ithin i ts mating r eceptacle, a nd t he mounting
holes at the front of the card are aligned with the mounting
boss threaded holes.
7
Use the screwdriver to secure the IP Packet Processor card
to the chassis with its provided mounting hardware (2X 4 -
40 x 1/4 pan head screws).
L–12
Revision 0
MN-CDM625A
