CDM-625A Advanced Satellite Modem
CDM-625A ODU (Transceiver, BUC, LNB) Operation
ODU: FSK-control  CSAT (2CSATs  CSAT #X)  Monitor
10.3.3.3.3.1.2
Monitor:
Tx
To view these read-only displays, use the
Supplies, and then press ENTER.
Press ENTER or CLEAR after viewing any Monitor screen to return to the previous menu.
ODU: FSK-control  CSAT (2CSATs  CSAT #X)  Monitor  Tx
Tx: SynTune = 09.6 VDC
ODU: FSK-control  CSAT (2CSATs  CSAT #X)  Monitor  Rx
Rx: SynTuneE = 01.4 VDC
ODU: FSK-control  CSAT (2CSATs  CSAT #X)  Monitor  Misc
Misc: Ref-Tune = 03.0 VDC
ODU: FSK-control  CSAT (2CSATs  CSAT #X)  Monitor  Power-
Supplies
24V=24.1 VDC
20V=21.2 VDC
ODU: FSK-control  CSAT (2CSATs  CSAT #X)  Alarms
10.3.3.3.3.1.3
Alarms:
◄ ►
Use the arrow keys to select Current-Alarms or Stored-Alarms, and then press ENTER.
Rx Misc
IFLO = 11.1 VDC
IFLO = 11.2 VDC
LNA = 00.05 mA
12V=12.5VDC
10V=10.2VDC
Current-Alarms
Power-Supplies
◄ ►
arrow keys to select Tx, Rx, Misc, or Power-
Power = <24 dBm
Temp = 26 C
Temp = 26 C
Fan = 550 mA
+5V=+5.4VDC
-5V=-5.3VDC
Stored-Alarms ()
10–18
Revision 0
MN-CDM625A
()
