Comtech EF Data CDM-625A Installation And Operation Manual page 310

CDM-625A Advanced Satellite Modem
Serial-based Remote Product Management
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
RTC Time TIM= 6 bytes
EDMAC EFM= 1 byte, 0 or 1
Framing Mode
EDMAC Slave ESA= 4 bytes
Address Range
One Ti m e OTO= 1 byte, value of
EDMAC Slave 0 or 1
Overwrite
Engineering ESC= 1 byte, 0 or 1
Service
Channel
Description of Arguments
Command or Query.
A time in the form hhmmss, indicating the time from midnight, where:
hh = hours (00 to 23)
mm = minutes (00 to 59)
ss = seconds (00 to 59)
Example: TIM=231259 (23 hours:12 minutes:59 seconds)
Command or Query.
EDMAC mode in the form x, where:
0=EDMAC OFF (Idle Mode)
1=EDMAC ON (Master Mode)
2=EDMAC ON (Slave Mode, Query Only)
Example: EFM=1 (EDMAC Enabled as Master)
Command or Query.
EDMAC Slave Address Range - sets the range of addresses of distant-end units (modems or transceivers) that this unit,
as the Master, will forward messages for. Only values which are integer multiples of ten are permitted. (0010, 0020, 0030,
0040 etc.)
Example: ESA=0090
This command is only valid for an EDMAC master. When used as a Query, it may be sent to an EDMAC slave, which will
respond with the appropriate address.
Command or Query.
One Time Overwrite to EDMAC Slave modem in the form x, where:
0=Off
1=On
Examples:
OTO=1 causes EDMAC Slave modem to be able to accept ONE remote control command locally after OTO=1 command.
OTO=0 turns off One Time Overwrite, only EDMAC command from EDMAC Master modem will be accepted by Slave
modem.
Command or Query. (IBS and ESC++ feature)
ESC in the form x, where:
0 = Disable the high-rate ESC
1 = Enable the high-rate ESC
IBS ESC may only be enabled when:
1. Both Tx and Rx framing modes are set to IBS.
2. Data rate is not 1544 kbps (as spare overhead bits are not available in this mode).
3. IBS high-rate ESC FAST option is enabled.
8–28
Revision 0
MN-CDM625A
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
TIM= TIM? TIM=hhmmss
TIM? (see Description of
TIM* Arguments)
TIM#
EFM= EFM? EFM=x
EFM? (see Description of
EFM* Arguments)
EFM#
ESA= ESA? ESA=xxxx
ESA? (see Description of
ESA* Arguments)
ESA#
OTO= OTO? OTO=x
OTO?
OTO* (see Description of
OTO# Arguments)
ESC= ESC? ESC=x
ESC? (see Description of
ESC* Arguments)
ESC#
