CDM-625A Advanced Satellite Modem
Introduction
ESC++ (NO REED SOLOMON)
No FEC, BPSK
No FEC, O/QPSK
VITERBI, BPSK, 1/2
VITERBI, O/QPSK, 1/2
VITERBI, O/QPSK, 3/4
VITERBI, O/QPSK, 7/8
SEQUENTIAL, BPSK, 1/2
SEQUENTIAL, O/QPSK, 1/2
SEQUENTIAL, O/QPSK, 3/4
SEQUENTIAL, O/QPSK, 7/8
TRELLIS, 8PSK, 2/3
TPC, BPSK, 5/16
TPC, BPSK, 21/44 (aka 1/2)
TPC, O/QPSK, 21/44 (aka 1/2)
TPC, O/QPSK, 3/4
TPC, O/QPSK, 17/18 (aka 0.95)
TPC, O/QPSK, 7/8
TPC, 8PSK/8-QAM, 3/4
TPC, 8PSK/8-QAM 17/18 (aka 0.95)
TPC, 8PSK/8-QAM, 7/8
TPC, 16-QAM, 3/4
TPC, 16-QAM, 7/8
LDPC, BPSK, 1/2
LDPC, O/QPSK, 1/2
LDPC, O/QPSK, 3/4
LDPC, O/QPSK, 2/3
LDPC, 8PSK/8-QAM, 3/4
LDPC, 8PSK/8-QAM,2/3
LDPC, 16-QAM, 3/4
ESC++ (ANY REED SOLOMON)
VITERBI, BPSK, 1/2
VITERBI, O/QPSK, 1/2
VITERBI, O/QPSK, 3/4
VITERBI, O/QPSK, 7/8
SEQUENTIAL, BPSK, 1/2
SEQUENTIAL, O/QPSK, 1/2
SEQUENTIAL, O/QPSK, 3/4
SEQUENTIAL, O/QPSK, 7/8
TRELLIS, 8PSK, 2/3
VITERBI, 16-QAM, 3/4
VITERBI, 16-QAM, 7/8
Lower Limit (kbps)
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
Lower Limit (kbps)
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
1–27
Revision 0
MN-CDM625A
Upper Limit (kbps)
12304.6
24609.3
5921.0
12304.6
18457.0
21533.2
1024.0
2048.0
2048.0
2048.0
24609.3
3700.6
5651.9
11745.3
18457.0
23242.1
21533.2
24609.3
24609.3
24609.3
24609.3
24609.3
5921.0
12304.6
18457.0
16406.2
24609.3
24609.3
24609.3
Upper Limit (kbps)
5263.1
10937.5
16406.2
19140.6
1024.0
2048.0
2048.0
2048.0
21875.0
21875.0
21875.0
