Comtech EF Data CDM-625A Installation And Operation Manual page 344

CDM-625A Advanced Satellite Modem
Serial-based Remote Product Management
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Packet WMD= 1 byte, value 0
Processor thru 3
Working Mode
Dedicated DMP= 1 byte, value 0
Management thru 8
Port
Ethernet 2048 EFS= 1 byte, value 0
Frame Size or 1
Host Access List ACL= 1 byte, value 0
Enable/Disable or 1
Packet PRD= 1 byte, value 0
Processor or 1
Redundancy
Precision Time PTP= 1 byte, value 0
Protocol or 1
Precision Time PTM= 1 byte, value 0
Protocol or 1
Grandmaster
Command or Query.
Packet Processor Working Mode in the form x, where:
0 = Managed Switch
1 = Router Point to Point*
2 = Router Multipoint Hub*
3 = Router Multipoint Remote*
*Note: Settings 1 through 3 apply to modem only with IP Packet Processor option card installed and enabled.
Command or Query.
Dedicated Ethernet Management port in Redundancy system in the form x, where:
0 = Disabled (Any Ethernet port can do management, default value)
1 = Port 1
2 = Port 2
3 = Port 3
4 = Port 4
5 = Port 1 – Local only*
6 = Port 2 – Local only*
7 = Port 3 – Local only*
8 = Port 4 – Local only*
Notes:
1. VLAN must be Disabled to be able to select a port as Dedicated Management Port.
2. * Only LAN devices can access M&C of modem. NO remote modem access.
Command or Query.
2048 byte Ethernet Frame Size Enable/Disable in the form x, where:
0 = 2048 Ethernet Frame Size is Disabled
1 = 2048 Ethernet Frame Size is Enabled (supported by modem with baseboard hardware Rev2 and above)
Command or Query.
IP Host Access List Enable/Disable in the form x, where:
0 = Host Access List is Disabled
1 = Host Access List is Enabled
Command or Query.
Valid only when Packet Processor is installed and Enabled.
Packet Processor Redundancy Enable/Disable, where:
0 = Disable Packet Processor Redundancy
1 = Enable Packet Processor Redundancy
Command or Query.
Precision Time Protocol Feature Enable/Disable in the form x, where:
0 = PTP is Disabled
1 = PTP Enabled
Command or Query.
Precision Time Protocol Grandmaster selection in the form x, where:
0 = Grandmaster reachable over LAN.
1 = Grandmaster reachable over WAN.
Description of Arguments
8–62
Revision 0
MN-CDM625A
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
WMD= WMD? WMD=x
WMD? (see Description of
WMD* Arguments)
WMD#
DMP= DMP? DMP=x
DMP? (see Description of
DMP* Arguments)
DMP#
EFS= EFS? EFS=x
EFS? (see Description of
EFS* Arguments)
EFS#
ACL= ACL? ACL=x
ACL? (see Description of
ACL* Arguments)
ACL#
PRD= PRD? PRD=x
PRD? (see Description of
PRD* Arguments)
PRD#
PTP= PTP? PTP=x
PTP? (see Description of
PTP* Arguments)
PTP#
PTM= PTM? PTM=x
PTM? (see Description of
PTM* Arguments)
PTM#
