62
Under Analog Output (Main) , you can specify the settings you want for
3
your analog output from MXO2 Mini. Under HDMI Output (Secondary)
you can specify the settings you want for your secondary HDMI output.
Depending on your sequence's video format, you may not be able to change
some of the settings.
$
$
$
$
Chapter 8, Using Matrox MXO2 with Adobe Premiere Pro
Format Use this to select the video format you want for your outputs.
For a list of the supported formats, see
Pro" on page 300.
Pulldown Method
method you want to be applied to your video output ( Standard 2:3 or
Advanced 2:3:3:2 ). Depending on your sequence's frame rate and the
current video output format, a pulldown method may automatically be
selected.
Use this to select the setup level you want for your
Setup (NTSC)
NTSC analog video. This affects both the NTSC analog video input and
output.
0 IRE Applies a setup level of 0 IRE. You should select this option
•
only when working with a commercial DV device that uses the
Japanese analog NTSC setup of 0 IRE. For example, if the video
appears too bright when you play back DV clips on your NTSC
monitor, you can change the setup to 0 IRE to output your DV clips at
the correct brightness.
Applies the standard NTSC setup level of 7.5 IRE.
7.5 IRE
•
Aspect Ratio Conversion
video to be output when upscaling or downscaling:
16x9 Letterbox
•
mode by adding black bars at the top and bottom of the picture for
display on a standard 4:3 television screen.
4x3 Pillarbox Outputs the standard 4:3 picture in pillarbox mode by
•
adding black bars to the left and right sides of the picture for display on
a widescreen 16:9 television screen.
Anamorphic Outputs the widescreen 16:9 picture as horizontally
•
compressed 4:3 video, which retains the picture's full vertical
resolution for display on a widescreen television. To display the video
with the correct proportions on an NTSC or PAL monitor, select the
16:9 display setting on the monitor.
Center Cut Outputs the widescreen 16:9 picture by evenly cropping
•
the left and right sides of the picture for display on a standard 4:3
television screen.
"Playback using Adobe Premiere
If this setting is available, select the pulldown
Use this to specify how you want your
Outputs the widescreen 16:9 picture in letterbox
