176
$
$
Under HDMI Output , you can specify your HDMI output format and type.
6
$
$
$
Chapter 11, Using Matrox A/V Tools
indicate that the output will be available on all the analog outputs. If
you're outputting HD analog video, the output type will be set to
.
Component
Setup (NTSC) Use this to select the setup level you want for your
NTSC analog video. This affects both the NTSC analog video input and
output.
Applies a setup level of 0 IRE. You should select this option
0 IRE
•
only when working with a commercial DV device that uses the
Japanese analog NTSC setup of 0 IRE. For example, if the video
appears too bright when you play back DV clips on your NTSC
monitor, you can change the setup to 0 IRE to output your DV clips at
the correct brightness.
Applies the standard NTSC setup level of 7.5 IRE.
7.5 IRE
•
YUV/RGB Select YUV or RGB to set the type of video signal that is
sent from the component output. For example, select RGB if you
connected the component output to a device that accepts an RGB signal.
Format Use this to specify whether you want the format for your
HDMI output to be the same as the main or secondary output.
Select the type of video signal that you want to be sent from
YUV/RGB
the HDMI output:
YUV Outputs YUV HDMI video. Select this only if you connected
•
the HDMI output to a device that accepts a YUV signal.
RGB - calibrated
•
currently loaded Matrox HDMI calibration settings for your HDMI
monitor or television. For details on calibrating your HDMI monitor
and loading calibration settings using the Matrox HDMI Calibration
Utility, see Chapter 7, "Calibrating Your HDMI Monitor for
RGB - native Outputs native RGB HDMI video that does not apply
•
any calibration compensation. This is useful when you want to output
RGB HDMI video to a device other than an HDMI monitor or
television, such as an HDMI recorder to perform an export to tape.
3D Viewing Mode
from the HDMI output to your 3D monitor:
Disabled Select this if you're not outputting 3D video, or to disable
•
3D video output. You can still monitor 3D video, but you must select
the correct viewing mode on your 3D monitor manually.
Side-by-side Outputs horizontally compressed side-by-side 3D
•
video (also referred to as side-by-side horizontal).
Outputs adjusted RGB HDMI video using the
Select the 3D signal type that you want to be sent
Video."
