58
Under Main Output and Secondary Output , you can specify the settings
3
you want for your main and secondary outputs from MXO2. Depending on
your sequence's video format, you may not be able to change some of the
settings.
$
$
$
¦ Note
secondary outputs, the same setting will be applied to both outputs.
Under Analog Output , you can specify your analog output format, NTSC
4
setup level, and output type:
$
$
Chapter 8, Using Matrox MXO2 with Adobe Premiere Pro
Format Use this to select the video format you want for your outputs.
Be aware that the format you select may not be supported on all the
MXO2 outputs. For a list of the supported formats, see
Adobe Premiere Pro"
Pulldown Method
method you want to be applied to your video output ( Standard 2:3 or
Advanced 2:3:3:2 ). Depending on your sequence's frame rate and the
current video output format, a pulldown method may automatically be
selected.
Aspect Ratio Conversion
video to be output when upscaling or downscaling:
16x9 Letterbox
•
mode by adding black bars at the top and bottom of the picture for
display on a standard 4:3 television screen.
Outputs the standard 4:3 picture in pillarbox mode by
4x3 Pillarbox
•
adding black bars to the left and right sides of the picture for display on
a widescreen 16:9 television screen.
Anamorphic Outputs the widescreen 16:9 picture as horizontally
•
compressed 4:3 video, which retains the picture's full vertical
resolution for display on a widescreen television. To display the video
with the correct proportions on an NTSC or PAL monitor, select the
16:9 display setting on the monitor.
Outputs the widescreen 16:9 picture by evenly cropping
Center Cut
•
the left and right sides of the picture for display on a standard 4:3
television screen.
Center Zoom Outputs the standard 4:3 picture by evenly cropping
•
the top and bottom edges of the picture for display on a widescreen
16:9 television screen.
When aspect ratio conversion is applied to both the main and
Format Use this to specify whether you want the format for the analog
outputs to be the same as the main or secondary output.
Output Type Specifies the analog video output type. If you're
outputting SD analog video, the output type will be set to All Available to
on page 300.
If this setting is available, select the pulldown
Use this to specify how you want your
Outputs the widescreen 16:9 picture in letterbox
"Playback using
