Click this button to select a color for your border.
Color
$
Balance Lets you adjust the prominence of the border between image A
$
and image B. For example, positive values make the border more
prominent in image B, while negative values make the border more
prominent in image A.
Click this button to restore the default Border values.
Reset
$
Use the controls under Softness to create a soft edge on the border of your
3
wipe.
Nonlinear softness
$
useful to clear this option when using certain wipe patterns. For example,
nonlinear softness often provides better results when creating SMPTE
wipes, while linear softness is usually preferable when creating organic
wipes.
Lets you adjust the amount of softness by dragging the slider
Amount
$
or entering a percentage in the text box. The higher the value, the less
sharp the edge of your border or wipe will become.
Reset Click this button at any time to restore the default Softness
$
values.
Use the controls under Preview to preview your wipe transition on your
4
video monitor (the preview will not appear in the Program monitor):
Drag the slider beside the Play button to scrub through your transition.
$
Click the Play button or press the
$
Select Loop if you'd like the wipe to play back continuously until you
click Stop .
You can adjust the wipe settings as your transition is playing to immediately
see the result of your changes.
Use the controls under Presets to save and load your wipe transition
5
settings. You can also create default settings for your wipe transitions.
Save Allows you to save your organic wipe settings to a file for future
$
use. When you click the Save button, the Save As dialog box opens and
allows you to name your effect and save it as a Matrox wipe transition
(.mwt) file.
Load Click this button to load a previously created .mwt file.
$
Set as Default
$
for Matrox wipe transitions.
Restore Default
$
specified using the Set as Default button.
For more information about setting up transitions, see your Adobe Premiere Pro
documentation.
This option is selected by default. You may find it
SPACEBAR
Sets your current wipe settings as the default settings
Click this button to restore the default settings you
to play back your transition.
Creating a wipe transition
