Matrox MXO2 Installation And User Manual page 248

228
Under SDI Audio Output Format , select the bit depth you want for your
3
embedded SDI audio output ( 20-bit or 24-bit ). This setting is not available
on MXO2 Mini.
Under Analog Audio Volume , drag the sliders to adjust the volume of your
4
analog audio output. By default, the sliders are locked so that they move
together. To move each slider independently, click the lock button (
disable it.
Under Advanced , you can use the Analog SC/H Phase slider to advance or
5
delay your analog video output's subcarrier phase with respect to the
horizontal sync of the genlock source (for composite video only). This
setting is not available on MXO2 Mini.
Click OK to save your settings.
6
Chapter 15, Using Matrox MXO2 with Telestream Wirecast
HDMI video from MXO2 using its native color settings for previewing
video on your HDMI monitor.
) to
