Over/Under
•
bottom).
¦ Note This feature may not be supported on some 3D monitors.
Under SDI Output , specify whether you want the format for your SDI
7
output to be the same as the main or secondary output.
Under Advanced , you can specify advanced video output settings.
8
Analog SC/H Phase
$
video output's subcarrier phase with respect to the horizontal sync of the
genlock source (for composite video only).
¦ Note This setting is unavailable until a clip is added to the clip list and you
click the Disk button.
Allow Super White/Allow Super Black
$
to allow the highest luminance level of your video output to exceed the
standard maximum white level. Select Allow Super Black to allow the
lowest luminance level of your video output to fall below the standard
black level. These options apply to all video outputs.
¦ Note Super white and super black should not be allowed when producing
your final video production for broadcast.
Click OK to save your settings.
9
Outputs over/under 3D video (also referred to as top
Use this slider to advance or delay your analog
Select Allow Super White
Defining your A/V Tools options
177
