system. That is, when you shut down your system, your MXO2 will turn off.
Starting up your system turns your MXO2 on. To manually turn your MXO2 on,
press the power button. To turn off your MXO2, press and hold the power button
for at least two seconds.
¡ Important When MXO2 is connected to a computer that is running, do not
disconnect MXO2 from its power source, or power off MXO2. Shut down your
computer before removing power from MXO2. If using a battery to power
MXO2, ensure that the battery is sufficiently charged.
External
power supply
Power cord
To AC
outlet
Power
button
Female 4-pin
XLR cable
MXO2
(side view)
OR
²Caution When
disconnecting the
power supply from
MXO2, make sure that
you slide back the
casing on the connector
to release the locking
mechanism.
Matrox battery
power cable
Battery on a
universal battery
adapter
15
Powering MXO2
