Setting the matrix IP address
The field contains the IP address of the connected matrix switcher.
Matrix IP Address
This value is encoded in the flash memory on the switcher.
Valid IP addresses consist of four 1-, 2-, or 3-digit numeric subfields separated by dots
(periods). Each field can be numbered from
total per field, are optional. Values of
The default address is 192.168.254.254, but if this conflicts with other equipment at your
installation, you can change the IP address to any valid value.
Edit the address field as follows:
1. Click in the
Matrix IP Address
2. Make any desired changes to the address.
3. Press the <Tab> key on the keyboard or click in another field to exit the
field.
Address
4. Click the button to make the address change take effect.
Take
NOTE: Editing the
IP Address
disconnect your from the HDXP. It is recommended that you connect via
RS-232 or RS-422 to edit this field.
Setting the Extron name or descriptor
The
Extron Name/Descriptor
when the HDXP switcher e-mails notification of its failed or repaired status. The default
name or descriptor shown in this field is a portion of your product name, followed by the
last six characters of the unit MAC address (for example,
This descriptor can be changed to any valid name, up to 24 alphanumeric characters
including forward slash ( ) and hyphen (
/
NOTE: The following characters are invalid or not recommended in the Extron Name/
Descriptor field:
+ ~ , @ = ' [] {} < > ' " " ; : | \ ?
Edit the Extron Name/Descriptor field as follows:
1. Click in the
Extron Name/Descriptor
cursor.
2.
Edit the name as desired.
3. Press the <Tab> key on the keyboard or click in another field to exit the
field.
Name/Descriptor
4. Click the button to make the name change take effect.
Take
through
000 255
and above are invalid.
256
field. The graphic cursor becomes a text cursor.
field while connected via Ethernet can immediately
field contains the name used as the "from" information
HDXP-Plus-Serie-05-A6-2D
).
-
field. The graphic cursor becomes a text
HDXP Plus Series Switchers • Matrix Software
. Leading zeros, up to 3 digits
Matrix IP
and {space}.
