Resetting using the rear panel Reset button
The rear panel has a Reset button that initiates four levels of matrix switcher resets. This
button is recessed; it can be accessed with a pointed stylus, ballpoint pen, or an Extron
Tweeker (a small screwdriver provided with the unit). While the switcher is running or while
you are applying power to it, press and hold in the button for the number of seconds
required for the desired reset level.
The table below provides a summary of the rear panel reset modes.
Mode Activation
1 Hold in the Reset button while applying
power to the switcher.
3 Hold in the Reset button until
the Reset LED blinks once (after
approximately 3 seconds); then within
1 second press Reset momentarily
(for less than 1 second).
4
Hold in the Reset button until the
Reset LED blinks twice (once after
approximately 3 seconds and again
after 6 seconds); then within 1 second
press Reset momentarily (for less than
1 second).
5 Hold in the Reset button until the
Reset LED blinks three times (once
after approximately 3 seconds, again
after 6 seconds, and then again after
9 seconds); then within 1 second
press Reset momentarily (for less than
1 second).
NOTE: Mode 5 reset clears most adjustments. To save these settings, use the Matrix Switchers
Control Program and select
perform this reset (see the Matrix Switcher Control Program help file for more information).
Reset Modes Summary
Result
Restores the factory-installed firmware. It
does not clear the current configuration.
Turns events (such as on and off. During
resetting, the Reset LED blinks two times
if events are starting or three times if
events are stopping.
• Enables ARP capability.
• Sets the IP address, subnet address,
and gateway address to the factory
defaults.
Sets port mapping to the factory
•
default.
• Turns DHCP off.
Turn events off.
•
The Reset LED blinks four times in quick
succession during the reset.
Performs a complete reset to factory
defaults (with the exception of the
firmware), which includes:
• Everything mode 4 does
Reset of almost all real time
•
adjustments:
Clears all ties, presets, audio or
•
RS-232 mutes, and I/O grouping.
Resets all IP options.
•
Removes or clears all switcher
•
files.
The reset LED blinks four times in quick
succession during the reset.
Save MATRIX settings as...
HDXP Plus Series Switchers • Operation
Purpose
Mode 1 can be
used to remove a
version of firmware
if incompatibility
issues arise.
Mode 3 is useful
for troubleshooting.
Mode 4 enables
you to set
IP address
information using
ARP and the MAC
address.
It does not replace
any user-installed
firmware.
Mode 5 is useful
if you want to
start over with
configuration and
uploading and also
to replace events.
from the menu before you
