Reference
Information
This section provides reference information on the HDXP Plus products. Topics include:
•
•

Mounting the Switcher

The HDXP matrix switchers are housed in rack-mountable metal enclosures with
mounting flanges for standard 19-inch racks. If desired, rack mount the HDXP switcher as
follows:
1.
2.
Figure 108 shows a diagram of an HDXP 1616 or 3216 being mounted to a standard
19-inch rack.
Figure 108.
Mounting the Switcher
Setting an IP Address
Insert the switcher into the rack, aligning the holes in the mounting flanges with those
in the rack.
Secure the switcher to the rack using the supplied bolts.
Rack Mounting the HDXP
