Creating Button Labels

The button caps are pre-labeled for your convenience by default. However,
you can replace the labels of the input and output buttons with the included
additional printed button labels or with labels that you create and print yourself.
You can temporarily remove the numbered translucent covers on the input and output
buttons to insert different labels behind the covers.
Page 95 contains
the guide, write button information in each button area as desired, and insert them in the
switcher input or output button caps. You can also create labels using the Button Label
Generator software.

Button Icons

The Extron Button-Label Generator software is provided with every Extron matrix switcher.
Each input and output button can be labeled with names, alphanumeric characters, or
color bitmaps for easy and intuitive input and output selection. See
on page 95 for blank labels and
for removing and replacing the translucent covers.
10
DVD
Figure 91.

Using the Button Label Generator

The Button Label Generator software creates labels for the HDXP input and output
buttons. You can create labels with names, alphanumeric characters, icons, and even
colored bitmaps for easy and intuitive input and output selection. See
Labels
changing the labels.
The program is contained on the same DVD as the Matrix Switcher Control Program, and
is installed automatically when you install the control software. By default, the software
installation creates a directory for the program at
Files (x86)
Label Generator
blank button labels. If desired, photocopy them or cut them out of
Using the Button Label Generator
13
VCR
Computer Computer
28 29 30 31 32
Document
Camera
Example of Button Labels on an HDXP Front Panel Section
