Global Presets Page

You can save and recall global presets from the Global Presets page. Access the Global
Presets page by clicking the
Figure 107.
Saving a preset
Save the current configuration (configuration 0) as a preset as follows:
1. Click the
2. Select the desired preset by clicking one of the preset buttons.
To create a new preset, click one of the [unassigned] buttons.
•
To overwrite an existing preset, click its button.
•
3. Enter a name for the preset in the text field.
NOTES:
•
•
4. Click the
If you do not rename an unassigned button, the HDXP names the preset as
•
Preset nn (nn is the next available number).
If you do not rename an existing preset when it is overwritten, the HDXP retains
•
the same name.
Recalling a preset
To recall a global preset to be the current configuration, click the button for the desired
preset on the Global Presets page.
Global Presets
Global Presets Page
button. It changes to
Save Preset
Preset names are limited to 12 characters. Valid characters are 0 – 9, a – z, A – Z, and
special characters _ : = / and space.
The following characters are invalid or not recommended in preset names:
+ ~ , @ = '[ ] { } < > ' " ; : | \
button.
Accept
HDXP Plus Series Switchers • HTML Configuration and Control
link on the left panel of the Control page.
.
Select Preset...
and .
?
111
