Managing Ties

On the Matrix window, you can create, dissolve, and view input-to-output ties as follows:
• To create a tie, click and drag from an input box to an output box.
If
•
A broken line appears, connecting the two boxes. (If you want to undo the
preliminary tie at this point, click the
Click
If
•
The tie is made immediately (no
To remove a tie, drag the output box to its tied input box or to the trash can.
•
If
•
The tie line becomes broken. If you want to reinstate the tie at this point, click
Cancel
disappears.
If
•
The tie is undone immediately.
• To view information on a specific input or output device, position the cursor over
that device in the Matrix window. A pop-up window opens, showing the input and
output numbers, names (if captions were specified), details on the connections to that
device, and the frequency of the video signal being sent to or from it.
Figure 77.
has been selected from the
Hold/Verify Changes
to confirm the tie. The broken line becomes solid.
Take
has been selected from the
Immediate Changes
has been selected from the
Hold/Verify Changes
. The broken line becomes solid again. Click
Changes has been selected from the
Immediate
Matrix Window Section with Pop-up Information on Input 4
HDXP Plus Series Switchers • Matrix Software
