5. Press and release the Enter button.
Press the Enter button to
confirm the configuration
change.
ENTER
The Enter button
becomes unlit or returns to
background illumination.
Figure 28.
The configuration now is:
Input 5 tied to output 1, output 3, and output 8 (see figure 29).
Input 5 tied to
outputs 1, 3, 4, and 8.
Input
5
Figure 29.

Previewing an Input

You can preview any input by switching it to the preview output when the HDXP is in
preview mode. To preview an input:
1. Press the Esc
may be lit.
2. Press the Preview button in the I/O section. The Preview button lights red (the Matrix
button is unlit).
Press the Preview button to enter preview mode.
The button lights red when selected.
Figure 30.
NOTE: If an input has already been selected in preview mode, its button also
lights red when you press Preview.
All input and output buttons
become unlit or return to
background illumination.
Confirming the Tie Removal
1
3
Output
8
Example 3, Final Configuration
>
button to clear any input, output, or control button indicators that
I / O
MATRIX PREVIEW
Selecting Preview Mode
HDXP Plus Series Switchers • Operation 23
