Command
Information Requests (continued)
Request part number
Query controller firmware
version
Example:
Query controller firmware
version (verbose mode)
Response format: Ethernet protocol firmware version – firmware version – updated firmware version
Example:
Response:
Description
n.nn –
1.00(1.50-SDI Series – Wed, 04 Jan 2006 23:11:29 GMT) – 1.00*(1.57-SDI Series – Fri, 19 Apr 2013 20:02:35 GMT)
Meaningless data
HDXP 3216 firmware version
for this switcher model
NOTE: There are up to three separate sets of Extron firmware on which the HDXP can report: the HDXP Plus Series
control firmware, which is the overall control firmware; the Ethernet protocol firmware, which handles the Ethernet
interface; and the latest optional Extron firmware update, which is available at www.extron.com.
Request system status
Example:
View File Directory Commands
The response to the View File Directory command differs depending on whether the command is sent via an
NOTE:
RS-232, RS-422, or Telnet connection, or via a web browser connection.
View file directory
RS232/RS422 port and Telnet
X1(
= Firmware version
NOTE:
X2)
= Firmware version, verbose mode
X2@
= Power supply voltages and temperature
ASCII Command
(Host to Switcher)
N
Q
Q
0Q
0q
* Indicates the version running
S
S
E }
DF
HDXP Plus Series Switchers • Remote Configuration and Control
Response
Additional Description
(Switcher to Host)
] Show the HDXP part number:
60-nnn-01
HDXP 3232 = 60-797-01
HDXP 3216 = 60-790-01
HDXP 1616 = 60-876-01
X1( ]
View firmware version
the second decimal place.
] The factory-installed controller
1.23
firmware version is 1.23.
X1( X2) X1( X2) ] Provide a detailed status
of the Ethernet protocol
firmware, the HDXP firmware,
and any firmware upgrade.
The firmware that is currently
running is marked by an
asterisk (*). A caret (^)
indicates that the firmware has
a bad checksum or an invalid
load. ?.?? indicates that
firmware is not loaded.
(See below.)
Updated firmware version
X2@ ] Display power supply voltages
and internal temperature
]
3.29 and 5.51 are the power
3.29 5.15 91.40
supply voltages. 91.4 (°F) is
the unit internal temperature.
filename1,date/time,length
filename2,date/time,length
filename3,date/time,length
•••
filenamen,date/time,length
List user-supplied files that
have been uploaded to the
root (\) directory and any
subdirectories, followed by the
number of bytes of space left
in the entire directory.
{space remaining} bytes • left
Firmware version number to second decimal place.
Version – description – date and time of upload
Voltage • voltage • internal temperature
X1(
to
Upload date and time
X2@
.
]
]
]
]
] ]
