2. Press and release the View
Press the View button
to enter view-only mode.
CONTROL
VIEW
ENTER PRESET
The button lights
Figure 33. Entering View-only Mode
<
The View
•
• The Matrix button lights green.
All of the buttons for outputs that are not tied light green.
•
3. Select the input or output whose ties you wish to view by pressing its input or output
button.
Press and release the desired input button.
The button lights green.
1 2 3 4 5 6
17 18 19 20 21 22 23 24
Figure 34. Selecting an Input to View in View-only Mode
When you press the button for an input or an output that has ties, the buttons for
•
all the inputs and outputs tied to it light green.
When an output button for which there are no ties is pressed, the buttons also
•
light for all other outputs without ties.
NOTE: You can also view a set of ties by selecting a tied output. To demonstrate
this, note the number of a lit output button, and then press and release the
output button for an untied (unlit) output. Observe that all of the untied outputs
light. Then press the output button that you noted previously and observe that
the selected output button, the tied input button, and the output buttons light for
all of the outputs that are tied to the input.
4. To exit view-only mode, press View
(approximately 30 seconds).
Press the View button
to exit view-only mode.
All input and output buttons
become unlit or return to
VIEW
background illumination.
The View button becomes
unlit or returns to
background illumination.
Figure 35. Exiting View-only Mode
<
button.
ESC
red.
button lights red.
The buttons for outputs that are tied to the selected input light green.
1 2
7 8
The buttons for outputs that are not tied to the selected input are unlit.
<
again; or wait for the View
HDXP Plus Series Switchers • Operation
3 4 5 6 7 8
OUTPUT
<
button to turn off
