■ Advanced connections

DATA SOCKET (p. 12)
6-pin mini DIN socket to
connect to a TNC, etc. for
packet operation.
VIDEO OUT
to [VOUT] jack
Vout
GND
3.5(d) mm
ACC SOCKET (p. 12)
KEY ACC
REMOTE (p. 144)
Used for computer control and transceive
operation.
OPC-589
SM-20
DESKTOP (p. 151)
MICROPHONE
DATA
ANT2
INSTALLATION AND CONNECTIONS
(p. 152)
MIC
GND
ANT1
DC 13.8V
AH-4 (p. 20)
HEADPHONES
or
SPEAKER
Selectable with the
[PHONE/SPEAKER]
switch on the back of
the front panel.
EXTERNAL
SPEAKER (p. 151)
SP-7/SP-10
AH-2b
