Cw Normal Side; Voice 1St Menu; Keyer 1St Menu; Dtmf 1St Menu - Icom IC-7000 Instruction Manual

■ Miscellaneous (others) set mode

35 CW Normal Side

Selects the carrier point of CW mode from LSB and
USB.

36 VOICE 1st Menu

This item selects the first appearing menu when [F-1
VO] (S-1) is pushed, from "VOICE-RX/TX" or
"VOICE-Root."

37 KEYER 1st Menu

This item selects the first appearing menu when [F-2
KEY] (S-1) is pushed, from "KEYER-SEND" or
"KEYER-Root."

38 DTMF 1st Menu

This item selects the first appearing menu when [F-2
DTM] (S-1) is pushed, from "DTMF-SEND" or
"DTMF-Root."

39 Mode Select (SSB)

This item inhibits the selection of SSB (LSB/USB)
modes, and allows you to simplify operation during
normal operation.
For example if you are operating mobile and only plan
on using FM and AM modes, sets all other modes
(SSB, CW, RTTY, WFM) to OFF, thereby making se-
lection of AM or FM quick and easy.

40 Mode Select (CW)

This item inhibits the selection of CW/CW-R modes,
and allows you to simplify operation during normal op-
eration.

41 Mode Select (RTTY)

This item inhibits the selection of RTTY/RTTY-R
modes, and allows you to simplify operation during
normal operation.
(continued)
LSB
The carrier point is set to
LSB side.
(default)
VOICE-RX/TX
Voice RX/TX menu is se-
lected. (default)
KEYER-SEND
Keyer send menu is se-
lected. (default)
DTMF-SEND
DTMF send menu is se-
lected. (default)
ON
SSB modes are selectable.
(default)
ON
CW modes are selectable.
(default)
ON
RTTY modes are selectable.
(default)
13
SET MODE
USB
The carrier point is set to
USB side.
VOICE-Root
Voice root menu is selected.
KEYER-Root
Keyer root menu is selected.
DTMF-Root
DTMF root menu is se-
lected.
OFF
SSB modes are inhibited.
OFF
CW modes are inhibited.
OFF
RTTY modes are inhibited.
13
136
