Scope set mode (Continued)

1 Max Hold

This item turns the peak level holding function ON
and OFF.

2 Scope Size

This item turns the scope size setting normal and
wide.

3 FAST Sweep

This item selects the sweep speed setting.

4 FAST Sweep Sound

This item sets the monitoring sound level for fast
sweeping.

■ Preamp and attenuator

The preamp amplifies received signals in the receiver
input (front end) circuit to improve the S/N ratio and
sensitivity. Turn this function ON when receiving weak
signals.
The attenuator prevents a strong undesired signal
near the desired frequency or near your location,
such as from a broadcast station, from causing dis-
tortion or spurious signals.
Push [P.AMP/ATT] momentarily to turn the preamp
ON and OFF; push and hold for 1 sec. to turn the at-
tenuator ON.
• " " appears when the preamp is ON; "
pears when the 12 dB attenuator is ON.
• Only one of these functions can be activated at a time.
ON
Peak hold is turned ON.
(default)
Normal
Normal size is selected.
(default)
Continuous
Push [F-4 SPD] momentar-
ily to toggle the sweep
speed Fast and Slow contin-
uously. (default)
-10dB :
Monitoring sound is set 10 dB smaller than
normal sound. (default)
:
0dB
Same as normal sound.
:
OFF
No sound comes out while fast sweeping
[P.AMP/ATT]
" ap-
momentarily
FUNCTIONS FOR RECEIVE
OFF
Peak hold is turned OFF.
Wide
Wide size is selected.
1 Sweep
Sweep speed changes Slow
to Fast just for one sweep
every pushing [F-4 SPD]
momentarily.
" " or " " appears.
momentarily
1 sec.
5
5
.
