13
SET MODE
■ Miscellaneous (others) set mode

7 RF/SQL Control

The [RF/SQL] control can be set as the RF/squelch
control (default), the squelch control only (RF gain is
fixed at maximum) or 'Auto' (RF gain control in SSB,
CW and RTTY; squelch control in AM and FM).
See pgs. 1, 35 for details.

8 Quick SPLIT

When this item is set to ON, pushing and holding [F-1
SPL] (M-1) for 1 sec. sets the undisplayed VFO fre-
quency to the displayed VFO frequency plus the split
offset and activates split operation.
See p. 92 for details.

9 SPLIT Offset

This item sets the offset (difference between transmit
and receive frequencies) for the quick split function.
The offset frequency can be set from –9.999 MHz to
+9.999 MHz in 1 kHz steps.

10 SPLIT LOCK

When this item is ON, [DIAL] can be used to adjust
the transmit frequency while pushing [XFC] even
while the lock function is activated.
See p. 91 for split frequency operation details.

11 DUP Offset HF

This item sets the offset (difference between transmit
and receive frequencies) for duplex operation. How-
ever, this setting is used to input the repeater offset
for an HF band only.
The offset frequency can be set from 0.000 MHz to
+9.999 MHz in 1 kHz steps.

12 DUP Offset 50M

This item sets the offset (difference between transmit
and receive frequencies) for duplex operation. How-
ever, this setting is used to input the repeater offset
for the 50 MHz band.
The offset frequency can be set from 0.000 MHz to
+9.999 MHz in 1 kHz steps.
131
(continued)
[RF/SQL] control as RF/squelch control
RF+SQL
[RF/SQL] control as squelch control
SQL
[RF/SQL] control as RF gain control in SSB,
AUTO
CW and RTTY; squelch control in AM and
FM (default)
ON
Quick split ON
(default)
0.000MHz
0.000 MHz offset
(default)
ON
Split lock function ON
0.100MHz
0.1 MHz offset (default)
0.500MHz
0.5 MHz offset (default)
OFF
Quick split OFF
-9.999MHz
Minus 9.999 MHz offset
OFF
Split lock function OFF
(default)
