Specifications; General; Transmitter; Receiver - Icom IC-7000 Instruction Manual

■ General

• Frequency coverage :
Receive
30 kHz –199.999999 MHz*
400–470.000000 MHz* 1
Transmit
1.800–1.999999 MHz* 2 , 3.500–3.999999 MHz*
5.33050* 3 , 5.34650* 3 , 5.36650*
5.37150* 3 , 5.40350* 3 ,
7.000–7.300 MHz* 2 ,
14.000–14.350 MHz* 2 ,
21.000–21.450 MHz* 2 ,
28.000–29.700 MHz* 2 ,
144.000–148.000 MHz*
* 1 Some frequency bands are not guaranteed.
* 2 Depending on version. * 3 USA version only.
• Mode : SSB, CW, RTTY, AM, FM, WFM
(WFM is for receive only)
• Number of memory CH: 503
(split memory: 99
edges: 6; call channel: 2 )
• Antenna connector : SO-239
144/430 MHz)
• Usable temperature : –10°C to +60°C (+14°F to +140°F)
range
• Frequency stability : Less than ± 0.5 ppm
(0°C to + 50°C; + 32°F to +122°F)
• Power supply : 13.8 V DC±15% (negative ground)
requirement
• Current drain : Transmit (at 100 W) 22 A
Receive squelched 1.3 A
(at 13.8 V DC)
• Dimensions : 167(W)
9
6 ⁄ (W)
(projections not included)
16
• Weight (approx.) : 2.3 kg (5 lb 1 oz)
• CI-V connector : 2-conductor 3.5 (d) mm (
• Video connector : 2-conductor 3.5 (d) mm (
• ACC connector : 13-pin
• Data connector : 6-pin

■ Transmitter

• Output power :
SSB, CW, FM, RTTY 2–100 W
2–50 W
2–35 W
AM 1–40 W
2–20 W
2–14 W
• Modulation system :
SSB Balanced modulation
AM Low level modulation
FM Variable reactance modulation
• Spurious emissions : Less than –60 dB*
*spurious freq.: below 30 MHz: –50 dB; above 50 MHz: –60 dB
• Carrier suppression : More than 50 dB
• Unwanted sideband : More than 50 dB
• Microphone : 8-pin modular jack (600 )
connector
• KEY connector : 3-conductor 6.35 (d) mm (
• RTTY connector : 3-conductor 3.5 (d) mm (
1 * 2
* 2
2
3 ,
10.100–10.150 MHz* 2 ,
18.068–18.168 MHz* 2 ,
24.890–24.990 MHz* 2 ,
50.000–54.000 MHz* 2 ,
2 , 430.000–450.000 MHz* 2
×
5 banks; scan
channels
×
2
(for HF/50 MHz and
/50
max. audio 1.6 A
× ×
58(H) 180(D) mm,
× ×
9 3
2 ⁄ (H) 7 ⁄ (D) in
32 32
1
⁄ ˝)
8
1
⁄ ˝)
8
(1.8–50 MHz bands)
(144 MHz band)
(430 MHz band)
(1.8–50 MHz bands)
(144 MHz band)
(430 MHz band)
1
⁄ ˝)
4
1
⁄ ˝)
8

SPECIFICATIONS

■ Receiver

• Receive system :
SSB/CW/RTTY/AM/FM Triple-conversion superheterodyne
WFM Double-conversion superheterodyne
• Intermediate frequencies:
1st
SSB/CW/RTTY/AM/FM 124.487 MHz
WFM 134.732 MHz
TV (Video) 69.0100 MHz
2nd
SSB/CW/RTTY/AM/FM 455 kHz
WFM 10.700 MHz
3rd
SSB/CW/RTTY/AM/FM 16.15 kHz
• Sensitivity ( :
at preamp ON)
Frequency SSB/CW/
AM
range RTTY
10 dB S/N
[MHz]
10 dB S/N
0.5–1.8 — 13 µV
1.8–28
0.15 µV 2.0 µV
28–29.995
50 MHz band 0.12 µV 1.0 µV
76–108 — —
144/430 MHz
0.11 µV 1.0 µV
bands
• Squelch sensitivity
(threshold; preamp ON)
SSB/CW/RTTY/AM Less than 5.6 µV
FM Less than 0.3 µV
• Selectivity :
SSB* More than 2.4 kHz/–6 dB
(BW=2.4 kHz)
Less than 3.6 kHz/–60 dB
CW* More than 500 Hz/–6 dB
(BW=500 Hz)
Less than 900 Hz/–60 dB
RTTY ) More than 360 Hz/–6 dB
(BW=350 Hz
Less than 650 Hz/–60 dB
AM More than 6.0 kHz/–6 dB
(BW=6 kHz)
Less than 15.0 kHz/–60 dB
FM More than 12.0 kHz/–6 dB
(BW=15 kHz)
Less than 20.0 kHz/–60 dB
*IF filter shape is set to SHARP.
• Spurious and image rejection ratio:
HF bands More than 70 dB
50 MHz band More than 70 dB
144/430 MHz band More than 65 dB
• Audio output power : More than 2.0 W
with an 8
• RIT variable range : ±9.99 kHz
• PHONES connector : 3-conductor 3.5 (d) mm (
• EXT SP connector : 2-conductor 3.5 (d) mm (
18
FM WFM
12 dB SINAD 12 dB SINAD
— —
— —
0.5 µV —
0.25 µV —
— 10.0 µV
0.18 µV —
:
17
18
(except IF/2 through)
(except IF through)
at 10% distortion
load (at 13.8 V DC)
1
⁄ ˝)/8
8
1
⁄ ˝)/8
8
150
