■ Connections for CW

[KEY]
[ACC]
For no break-in operation:
13
Connect an external switch
9 10 11 12
such as a foot switch; or use
5 6 7 8
the RTTY SEND terminal for
1 2 3 4
all bands. (See p. 23)
[MICROPHONE]
See p. 50 for connection details:
Paddle operation from [MIC]
connector .
Rear panel
Paddle
Straight key
Microphone (HM-103)
INSTALLATION AND CONNECTIONS
Keyer set mode (p. 49)
Keyer set mode setting
Paddle polarity
Keyer Type
Normal
Paddle polarity
Keyer Type
Reverse
Paddle polarity
Keyer Type
Paddle polarity
Keyer Type
Paddle polarity
Keyer Type
MIC U/D keyer (HM-103)
2
2
Normal
ELEC-KEY
Reverse
ELEC-KEY
Normal
BUG-KEY
B ug
Normal
Straight
Normal
ELEC-KEY
ON
22
