■ Front panel

q AF GAIN CONTROL [AF] (inner control; p. 33)
w RF GAIN CONTROL/SQUELCH CONTROL
[RF/SQL] (outer control; p. 35)
e POWER KEY [PWR] (p. 25)
r FRONT PANEL LATCH (p. 16)
t PASSBAND TUNING/M-ch/RIT CONTROLS
[PBT/M-ch/RIT] (pgs. 75, 79, 88, 102, 106)
y TWIN PBT (M-ch/RIT) INDICATOR
(pgs. 75, 79, 88, 102, 106)
u MENU/GROUP KEYS [MENU/GRP] (p. 153)
i TUNER/CALL KEY [TUNER/CALL]
(pgs. 102, 116)
o MULTI-FUNCTION KEYS [F1]/[F2]/[F3]/[F4]
(pgs. 5-8, 153)
!0 MANUAL NOTCH KEY [MNF/ADJ] (p. 83)
!1 AUTO NOTCH/VOICE RECORDER KEY
[ANF/• REC] (pgs. 82, 95)
!2 SPCH/LOCK KEY [SPCH/LOCK] (pgs. 34, 37)
!3 MICROPHONE CONNECTOR (p. 10)
!4 UP/DOWN (BAND) KEYS [Y(
!5 MAIN DIAL TENSION LATCH
!6 HEADPHONE JACK [PHONES] (p. 18)
!7 MAIN DIAL [DIAL]
!8 RECEIVE/TRANSMIT INDICATORS [RX]/[TX]
!9 TUNING STEP KEY [TS] (pgs. 30-32)
@0 NOISE BLANKER KEY [NB/ADJ] (p. 80)
@1 NOISE REDUCTION KEY [NR/LEV] (p. 81)
@2 FUNCTION DISPLAY (p. 13)
@3 PRE AMP/ATTENUATOR KEY [P.AMP/ATT]
(p. 74)
@4 MODE KEY [MODE] (p. 34)
i-3
)]/[Z( )]
BAND BAND
■ Microphone (HM-151)
z SPCH/LOCK KEY [SPCH/LOCK] (p. 34, 37)
x PTT SWITCH [PTT] (p. 37)
c UP/DOWN SWITCHES [Y]/[Z]
v TRANSMIT INDICATOR
b KEYPAD (pgs. 28, 29)
n FILTER SELECTION [FIL] (p. 77)
m MODE KEY [MODE] (p. 34)
, POWER INDICATOR
. PROGRAMMABLE FUNCTION KEYS [F-1]/[F-2]
⁄0 MEMORY WRITE [MW] (pgs. 103, 104)
⁄1 VFO/MEMORY SELECTION [V/M]
(pgs. 27, 102, 109)
⁄2 TRANSMIT FREQUENCY CHECK [XFC]
(pgs. 65, 91)
⁄3 TUNER/CALL KEY [TUNER/CALL]
(pgs. 102, 116)
