VITC Reader

Mykerinos boards are capable of reading Vertical Interval Time Code encoded in a lines of a video sig-
nal. VITC has the advantage of being accurate and readable even when the video is stationary.
Video Input
These check buttons allow the choice of which of the two video inputs will be used for the VITC signal.
Line
Shows which lines will be decoded. Although VITC code fits into a single line, it is normally duplicated to
provide redundancy reducing read errors. The drop-down lists allow any two lines to be chosen. Differ-
ent pairs of lines often carry different code. E.g. Time-of-day and Absolute time.

VITC Generator

Mykerinos boards have a Vertical Interval Time Code generator.
Enable
When checked the output of the VITC generator is On.
Video Output
These check buttons allow the choice of which of the two video outputs will be used for the VITC.
Line
Show which lines will contain VITC.
