Enabling Pyramix Virtual Studio with your Software Key

Pyramix Virtual Studio is protected by a special software Key. Once you have registered your software
you will be provided with this Key or Keys (depending on the chosen options).
Entering your Key(s)
After the Pyramix installation process you will be prompted to enter your Authorization Key. If you click
Yes the MT Security Settings dialog will be launched automatically, allowing the Key or Keys to be
entered immediately. If you choose not to enter your Key at this point you can do so later by choosing
one of the following procedures:
1. Double-click the file YourPersonalKeyXXXXX.mtk. This is attached to the email containing your
Key(s).
2. Open the MT Security Settings Control Panel
(Windows Task Bar Start > Control Panel > MT Security Settings),
click the Import Key button and browse for your Key file called
YourPersonalKeyXXXXX.mtk
3. Open the MT Security Settings Control Panel (as above), in the Registration section select the
board number corresponding to the serial number for your Keys or HASP Key for a dongle, click the
Enter Key button and type your User Name, Company Name and Key then click OK. Repeat this
step for each Keys listed in the email.

Changing or re-entering a Key

Should you need to subsequently change or re-enter a Key, follow the appropriate option above.
The key system is "smart". Only one key or set of keys is required regardless of the number of boards in
a system. Any card can hold this key set as the authorization is processed based on a "Logical OR" of
all keys present on any and all Mykerinos boards. Of course this Logical OR will only process keys with
identical User Name and Company Name to the one entered in the key enabling dialog box.
