Display Envelope - by default shows clips as blue blocks with yellow waveform and adds a
black line which allows the gain to be adjusted using the mouse by simply clicking and drag-
ging. Pressing the Ctrl key enables the drawing tool for envelopes. This also applies to Auto-
mation curves.
In each Track Header, you will find a pale green box with a number superimposed on it; and a pale
red box with a number superimposed on it. The green box shows the mixer channel number the Track
output is assigned TO. The red box shows the number of the physical input or Internal Return Bus
feeding the track input.
To change a Track input or Output assignment, just click on the corresponding Track input or output
icon, then select the appropriate Mixer channel number or Input number from the corresponding pop-
up list. Note: When channel and input numbers are the same, selecting a Mixer channel will also
change the Input number, otherwise they operate independently.
When Track inputs and outputs are not assigned, the corresponding boxes for that Track will have
dashes in them instead of numbers.
Many tracks can be assigned to the same Mixer input, they are therefore sub-mixed before entering the
Mixer. This allows more tracks to be played than the number of Mixer input strips.
Many tracks can be fed from the same physical input.
