Position/Speaker Control

When a single source is used, the Position Control is displayed as a green dot on a grid with 5 speaker
icons. Each speaker icon represents a Surround Speaker Position (L, C, R, SL, SR). The position of the
Green Dot determines the position of the source within the surround sound space. To position it, simply
left-click anywhere within the surround sound space. To position it, simply left-click on the control and
move it to the desired location. Double-clicking on the Green Dot automatically centers it.

Surround Panning Algorithm

The drop down list gives a choice of panning algorithms.
Constant Gain
Allows the surround panning to preserve a constant gain sum on all speakers wherever the Position
Control is placed.
Constant Power
Allows the surround panning to preserve a constant power sum on all speakers wherever the Position
Control is placed.
