Jog Settings
Speed ceiling
Four Radio Buttons offer the choice of 1X, 2X, 3X or 4X nominal play speed.
Sensitivity
The value typed in the box (in seconds) determines the number of seconds the transport will move per
revolution of an attached physical jog wheel.
Smoothing Filter
The value typed in the box (in frames) determines the degree of smoothing that will be applied.
Transient response accelerator
The slider varies the jog response between the smoothest possible audio at one extreme and the great-
est positional accuracy, I.e. sync, at the other.
Auto Jog on move
Check the box to enable Auto Jog.
Mouse Scrubbing Settings
There are two possible scrub modes, Analog Tape Mode and Repeat Loop Mode check the appropri-
ate box for the required mode. The length of the loop in Repeat Loop Mode is related to the base sam-
pling frequency so the loop will be 116mS long at
192 kHz.
Scrub Settings
Audio Quality
Three Radio Buttons offer a choice between Standard, Improved or Best quality of scrubbed audio.
Standard is the default. High quality scrubbing is very processor intensive so Improved mode is limited
to a maximum of six active strips in the mixer. The Best best setting is for future use.

Transport Controls

The Play Head Cursor or the Timeline will move in response to the transport control buttons on the
strip at the bottom of the main Pyramix Virtual Studio by Merging Technologies window, or by using
the separate Transport window controls (providing control over the Internal machine is selected). Note
that the Transport Strip disappears when the Transport window is open, and reappears when the win-
dow is closed.
From left to right along the Transport strip, the controls are as follows:
The 'Grow Box' opens the full Transport Control window
A counter shows the current Play Head position.
User Manual : Navigation
44.1, 88.2 and 176.4 kHz or 106ms at 48, 96 and
Markers/Tracks Sync drop-down menu
