Default
Choosing Presets > Store > Default makes the current parameters the default. These can be from new
values or a previously recalled Preset
Modifying an Existing Plug-in Preset
To modify or update an existing preset, set the effect's parameters to the desired new settings. Right-
click and select Presets > Store then choose the Preset name in the list to update or modify. A Store
preset dialogue box will appear asking if you wish to replace the chosen Preset. Click OK to accept or
Cancel to reject. The new settings will overwrite the previous preset parameter settings.
Deleting Presets
To delete the current preset, right click in the effects window. Then choose Presets > Remove then
choose the preset you wish to remove.

Parametric EQ.

The Parametric Equalizer is a four band fully parametric EQ with independent control of boost and cut,
frequency, and bandwidth (Q factor) for each band. The master section at the top of the window
behaves as outlined earlier. The equalizer can be operated using the rotary controls at the bottom, by
directly entering numerical parameters in the boxes below the knobs or by clicking and dragging on one
of the four colored nodes. Left-clicking enables level and frequency to be adjusted, right-clicking then
dragging left or right allows adjustment of Q.
All bands are full range. Boost and cut of up to 24dB is available. Q can be set anywhere from 0.2
(wide) to 20 (narrow).
User Manual : Plug-Ins
Parametric EQ floating Window
220
