Plug-Ins

Common Master Section

Several of the following Pyramix plug-ins share a common Master Section.
On/Off (Bypass) Switch
The On/Off (bypass) switch activates and deactivates the effect.
Auto Gain Compensation
When this switch is lit Auto Gain Compensation is in circuit. The function is intended to keep the out-
put level of the plug-in approximately equal to the input level.
Output Gain
Manually adjusts the gain applied at the output of the plug-in. The value is shown in dB.
Channel List
Shows which channel has the plug-in that the window is currently controlling. Clicking the arrow drops
down a list of all channels that have this plug-in assigned to them. Click on a name to selected a chan-
nel from the list. The control values will change to reflect the current state of the plug-in on the selected
channel. This feature enables all instances of a particular plug-in to be controlled from the same inter-
face window without opening duplicate windows for each channel.
