DUAL Tab:
• If the Reference is not in Auto mode and the Sync Source (in the I/O & Sync Tab) is in Audio Input
mode, there should be a physical connection to the chosen reference.
• If the input level is simply too low, increase the Input Gain.
SDIF Tab:
• The Format (SDIF2 or SDIF3) must match the format of the incoming audio signal. Make certain the
SDIF daughter card is only connected to DSD.
TDIF tab:
• If the Reference is not in Auto mode and the Sync Source (in the I/O & Sync Tab) is in Audio Input
mode, there should be a physical connection to the chosen reference.
MADI (ver1 or ver2) Tab:
• Input Groups must be set accordingly to the used inputs.
• To activate the inputs 57 to 64, please set the MADI card to Extended Mode.
• In Audio Sync Source the outgoing MADI Word Clock should match the external equipment MADI
Word Clock.
• In MADI Word Clock Sync Source, the external incoming Word Clock should match the one set in
the MADI card.
In the Input Check window (right click on the bottom of Pyramix window / Debug menu):
• The input frequency should match the frequency set in the Mixer Settings.
• The yellow bar must be slightly visible in the Deviation field.
• The amount of jitter should be within a range of 0 to 100 ns, although higher values are possible.
For each input connection in the mixer, there should be a corresponding physical connection.
All audio tracks in use should be in Live Input or Auto mode. If this is not the case, all tracks
which are set in Repro mode, will be muted.
Pyramix should not be in Play mode. In this case, all the audio tracks in Auto mode will
switch to Repro mode and the corresponding inputs will be muted.

Clip Display Problems

No Waveform Display
Symptoms
Files are dragged into the Timeline from a mounted folder but no waveform is generated. Manually
invoking Generate Waveform doesn't work.
Solution
This problem with Waveform Generation is likely to be due to the fact that the audio files are in Read
Only mode. This will often be the case when copying files from a CD-ROM. In Windows Explorer simply
select all the tracks from the CD, right click, select Properties and uncheck the Read Only box under
Attributes.
