Mixer Surround Components

When a Surround Bus is added to the mixer an surround panner appears at the top on the Input
Strips
Open Surround Control
Speaker Controls
Double-clicking on any of the Speaker Controls toggles the mute on/off of the selected surround chan-
nel (also muting any audio routed to that surround channel output). When a channel control is muted, it
is no longer displayed on the Mixer Input Strip.

Joystick Panner

Determines the position of the source within the surround sound space. To position it, simply left-click
on the control and move it to the desired location. Double clicking on this control will automatically cen-
ter it.

Sub Level

Determines the level sent to the Sub (.1) output.

Surround Bus select

If a Multiple Surround Bus has been added to the mixer Select buttons appear here. The same number
of buttons as there are busses. The buttons toggle between the busses.
Destructive Solo
Solos the input. Will affect the main Surround bus output.
Joystick Panner
Surround Bus Select
User Manual : Creating and Configuring Mixers
Front Speaker controls
Rear Speaker controls
Sub Level
Destructive Solo
Strip Surround controls
