User Manual : Plug-Ins
carries a signal, it is displayed as a straight line at a 45° angle from the bottom right to the top left. If the
left and right channel are out of phase, this would result in a horizontal line.
A decent stereo mix would appear as a vertically shaped cloud as shown in the example below:
Phase-Oscillo floating Window
Phase-Oscillo configuration
The Phase-Oscillo plug-in has several buttons to configure it's operation.
Oscilloscope button
This switches the oscilloscope display on and off. If set to off, only the phase meter is displayed.
Sample interpolation
When this switch is on, the samples of the signals displayed on the oscilloscope are interconnected,
resulting in an increased readability of the display.
Setup
This button opens the set-up pane with further options
Working Priority
Choose one of these switches to select the amount of CPU time of the host PC which can be
consumed by the plug-in, and therefore influences the redraw speed and accuracy of the oscil-
loscope. The higher the priority, the more CPU time is assigned to the plug-in
Drop frame display
