Track Header Panel

The Track Header Panel contains a variety of buttons and information fields.
This screen shot shows Track Headers in variety of states.
Right clicking the automation icon pops up the Automation Overlay context menu with options as to
what is displayed.
The pale green block shows the number of the Mixer Channel Input it is assigned to. Click-
ing this icon pops up a list to select from all available Mixer Channel Inputs. If the pale green
block shows a dash, no Mixer Channel Input is selected and recording and or replay is not
possible.
Clicking the Track Name area opens a text entry box where the track name can be typed.
Track names default to Mono or Stereo.
View Automation Off - Automation data overlay is not displayed on the track.
View Automation On - Automation data overlay is displayed on the track.
The Mute icon toggles the Track Output between Un-Muted, as shown here;
and Track Output Muted, as shown here.
The Solo icon toggles the Track Output between Solo off, as shown here and;
Solo on as shown here.
User Manual : Tracks
Track Header Panel
123
