Similarly, for a channel input strip, right click on a blank area of the Strip. Right-clicking within a function
block adds menu entries to the top of the list, relevant to the specific block.

Mixer Configure Mode

To alter the mixer configuration and I/O assignments Configure Mode must be turned on. Right-click
anywhere on the Mixer window and select Configure. Note the XLR icons and numbers which appear
near the bottom of each Input Strip and Output Bus.

Adding Strips

Once Configure mode is turned ON, (a tick appears next to Configure in the list) Input Strips, Output
Buss and Group strips can be added to the mixer as required.
Right-click anywhere on the Mixer window, choose Strip > Add and select the appropriate type of strip
to add or right-click anywhere on the Mixer window, choose Bus > Add and select the appropriate type
of bus to add.

Removing Strips

To remove a given input strip, bus or group, right-click directly on it and choose Strip > Remove (Strip,
Bus or Group) as appropriate.

Mixer I/O Assignments

To or from physical I/O
To change I/O assignments to or from physical I/O or the Internal Return Busses, click on the appro-
priate XLR icon. A pop-up appears with a list of all valid choices.
From tracks
Note that several tracks may be routed to the same mixer input strip. Tracks are assigned to mixer input
strips either automatically or manually from the Track Header. See: Track Header Panel on page 123

Adding Plug-ins

Native Plug-ins

These include the eq and dynamics found on a conventional hardware mixer's channel strip. To add a
native plug-in right-click with the mouse cursor over the strip where the plug-in is to be added. If you
right-clicked in the effects area of the strip select Effects > Add. If you clicked somewhere else, select
Add Effect. Select an effect from the drop down list. It will appear in the strip.
User Manual : Creating and Configuring Mixers
I/O assignment pop-up
