Merging Pyramix 4.3 User Manual page 293

CD frames
Display as CD time
Waveform Display >
Larger
Smaller
x1
x2
x4
x8
dB
Auto-Scale Waveform
Show Full Waveform
Show Waveform Origin
Show Dynamic Waveform
Hide Clip Name when Waveform Shown
Zoom >
Fit in window
Previous zoom
Zoom In
Zoom Out
Recall Preset >
Zoom 1
Zoom 2
Zoom 3
Zoom 4
Zoom 5
Set Preset >
Zoom 1
Zoom 2
Zoom 3
Sets the < 1 second Cursor TimeCode display to display CD frames
Sets the TimeCode display to CD Track elapsed time (only available when CD
Markers are present)
Increase the size of the current waveform display
Decrease the size of the current waveform display
Sets the magnification factor of the current waveform display to 1x
Sets the magnification factor of the current waveform display to 2x
Sets the magnification factor of the current waveform display to 4x
Sets the magnification factor of the current waveform display to 8x
Sets the current waveform display to decibels
Sets the current waveform display to automatically display an optimal wave-
form
Sets the current waveform display to display a waveform that is fully colored
even at sample level (like peak display)
Sets the current waveform display to display a waveform that show also at
sample level the 0dB origin
Sets the current waveform display to display a waveform that shows the
dynamic range for each pixel
Hides the clip names when the waveform is displayed
Adjusts the horizontal magnification (zoom level) of the Project Editor panel to
fit the selected clip or region
Restores the Project Editor Panel view to the previous zoom resolution and
location
Zooms in by a factor of 2x, centered around the middle of the Project Editor
Panel
Zooms out by a factor of 2x, centered around the middle of the Project Editor
Panel
Recall Preset Zoom 1
Recall Preset Zoom 2
Recall Preset Zoom 3
Recall Preset Zoom 4
Recall Preset Zoom 5
Set Preset Zoom 1
Set Preset Zoom 2
Set Preset Zoom 3
User Manual : Menus - View Menu
User Manual
293
