Show/Hide DRC Section
Release Acceleration or
Modification Display
Offset Control
Velocity Control
Show/hide DRC section
DRC section on/off
Release Acceleration or Modification Display
Shows a curve which illustrates the relationship between the change in dynamics of the input signal and
the variation of the release time. The curve can be adapted between linear and power function charac-
teristics (see also the description of the Curve Control parameter). During playback the display will
also show a small red ball moving along the curve. This shows the range the algorithm is working in.
Gain reduction bargraph
Displays the gain reduction of the limiter while the DRC circuit is active. The scale is fixed at 6 dB.
Dynamics bargraph
Displays the dynamics of the input signal, which is the basis for the DRC algorithm.
Velocity control
Determines the speed of the DRC algorithm. The lower the value, the faster the algorithm reacts to
changes of the dynamics of the signal and the more it reacts to dynamics the more the release time will
remain constant.
Offset control
This parameter basically sets the minimum release time. In this sense the release control of the limiter
defines the maximum release time, so the release time determined by the DRC algorithm will vary
between these two times.
Curve control
This parameter controls the characteristics of the relationship between the dynamics of the signal and
the resulting release time
User Manual : Strip and Bus Tools - Plug-ins
DRC Section On/Off
Gain Reduction Bargraph
Dynamics Bargraph
Curve Control
Lookahead Delay Control
