Note: Sections remain active when hidden.
Section On/Off Button
Between the Show/Hide triangle and the Section Title is the On/Off button for the Section.
Input Section
Strip Name
Show/Hide Input Section
Input Level Control
Strip Name
Displays the name of the strip the plug-in is assigned to. The name for the plug-in can be changed by
double-clicking on the strip name, then typing in a name and hitting the Return key to confirm. If a plug-
in name is changed in this way, subsequent changes to the parent mixer-strip name do not affect the
plug-in strip name. To recover the name of the parent strip, simply remove the strip name.
The strip name is saved with presets and within Pyramix projects.
Activate/deactivate plug-in
This button switches the entire Strip plug-in on or off. Note that when the plug-in is switched off, it
doesn't consume any DSP power.
Show/Hide input section
Input section on/off
Input level control
Adjusts the input level over a range of -48 dB to +48 dB.
Show/hide Routing
By default Routing buttons are hidden. This button toggles between Showing and Hiding the Routing
Buttons. Routing remains active when hidden.
Routing Buttons
Determine which audio streams running through the strip will be processed by the plug-in. The number
of buttons depends on the number of steams controlled by the strip. Currently this means one for a
mono input channel or two for a stereo input channel but will be 8 for a 7.1 input channel. Streams
which are not selected will be left untouched.
User Manual : Strip and Bus Tools - Plug-ins
Activate/De-activate Plug-in
Input Section On/Off
Show/Hide Routing
Routing Buttons
