Sync
Source
This determines the sample clock source for the whole Pyramix system. If an external source is
selected and no valid signal is detected, the system reverts to Internal until the external signal is
restored. The following choices are available:
Internal
Selects the board's internal oscillator as clock master.
Video
Selects an external video input as the reference. The card derives word clock from the video sync rate.
A valid video signal must be connected to the Mykerinos board chosen as the Video / TC master in the
VS3 control panel.
Word Clock
Selects an external word clock source as the reference. The word clock must be connected to the Myk-
erinos board chosen as video / TC master in the VS3 control panel.
LTC
In special situations this option enables word clock to be derived from Linear TimeCode

Audio Input

Select this option if you want Pyramix to derive it's clock from an external audio source connected to
any of the daughtercard(s) present. The correct audio input must also be selected.
Input
Format
Provides input format selection. This is varies, depending on which Mykerinos Daughter card is cur-
rently selected by the Board drop-down menu.
Range
Shows the number of possible system inputs available depending on the Mykerinos Daughter
card currently selected Board drop-down menu.
Output
Mode
Provides output format selection. This is variable, depending on the Mykerinos Daughter card under
consideration.
Monitoring

Preferred Outputs

The monitoring outputs defined here will be used by the following system functions:
• The Auto-Connect function
• Monitoring in Media Libraries
• Digitizing Session monitoring
