The Fade Safe check box in the Fader section ensures (when checked) that all following fades to
the right of the one being edited are left intact while editing the current fade. This enables Auto-Rip-
ple to be used without Auto-Ripple while keeping Fade synchronization clean.
•
When the Force Safe box is checked the Fade Editor forces Fade Safe to enabled after each edit
change.
•
Six Memory Set and six Memory Recall buttons store and recall all the settings in the Fade Editor.
The recall buttons are only numbered when there are stored parameters to recall.
•
Gain Faders, Nudge buttons and Manual Entry Value Box (in dB) for both Fade Out & Fade In
•
Intercept and Asymmetry Faders, Nudge buttons and Manual Entry Value Box (in dB)
•
Length Faders, Nudge buttons and Manual Entry Value Box (in milliseconds. Type an s after any
numeric entry to obtain a value in seconds) for both Fade Out & In
•
Length of Fade Out & In can be linked by clicking the Link button
•
Length of Fade Out and In can be changed symmetrically (centered) by clicking the Mirror
button.
•
Position Faders, Nudge buttons and Manual Entry Value Box (in millisecond, type an s after any
number entry for a value in seconds) for both Fade Out & In
•
Position of Fade Out & In can be linked by clicking the Link button
•
Media Position Faders, Nudge buttons and Manual Entry
•
Value Box (in millisecond, type an s after any number entry for a value in seconds) for Fade In
Parameters & Options Section
In this table parameters and options may be modified by clicking on >.
There are these sections and fields:
Control
•
Link Length (see above)
•
Mirror Length (see above)
•
Link Position (see above)
•
Fade Safe (see above)
Display
•
Shown Tracks offers these choices:
•
All tracks
•
Follow TimeLine Display
•
Choice of tracks. The number of tracks selected in the TimeLine controls the available
choices. So, if 4 tracks are selected, there will be the option of 1, 2, 3, or 4 tracks
•
Auto-Center, enables automatic re-centering of the display around the Fade or Reference Point
after certain operations
•
None
•
Fade
•
Reference Point
•
Zoom, can be one of the following:
