Further Mixer Configuration Options; Mixer Context Pop-Up Menu - Merging Pyramix 4.3 User Manual

Direct X Plug-ins
To add a Direct X plug-in the procedure is the same except select Direct X Plug-In or Add Direct X
Plug-In.
Note: Plug-ins cannot be added to Monitor Busses and DirectX Plug-ins can only be
added to Input Strips or used in the FX Rack. Please see: Effects Rack on page 258

Further Mixer Configuration Options

Mixer Context Pop-up menu

The entries on this menu vary according to where you right-click on the mixer surface. At the top of the
menu the entries concern the specific mixer component under the mouse cursor when you right click.
The next section of the menu has entries which affect the Strip. Entries from Mixer to the end of the
menu affect the entire mixer and are available wherever the mouse is right-clicked.
Mixer > Show
Show All
Show / Hide >
Minimize
Automation >
Isolate
Play
Record
Auto-write
Memory >
Settings >
General...
Enable Delay Compensation Enables Delay Compensation for the mixer
Dithering
Remove
Makes all input strips and busses visible
Selects Strips and Busses to be shown or hidden. When checked, the Busses or
strips are visible on the console surface. Both Show and Hide access the same
lists.
When checked, Mixer window is minimized
These menu choices toggle the Automation mode for the entire
mixer. Please see: Automation on page 192
The choices here enable mixer presets to be saved loaded and managed.
Please see: Storing and Recalling Mixer Presets on page 77
Opens the Mixer Settings window Please see: Mixer Settings on page 112
Opens the Dithering window. Please see: below and Dither on page 247
for an explanation of the need for dither
Select All Strips , All Buses or All to remove groups of mixer components or
every component.
User Manual : Creating and Configuring Mixers
Mixer Show / Hide pop-up
75
User Manual
